MM-590 Condenser / Dynamic Bifunctional Microphone
*The product images and specifications shown on our website may differ from the actual products due to different versions.
- MM-590 is the first microphone that accepts both condenser and dynamic microphone capsule modules.
- For MU-90 condenser microphone capsule module, the power can be supplied by the built-in AA battery or external 48 V phantom power.
Product Introduction
| Model | MM-590 |
|---|---|
| Name | Condenser / Dynamic Bifunctional Microphone |
| Capsule Module | Condenser: MU-90 Dynamic: MU-59 |
| Polar Pattern | Supercardioid |
| Housing | Zinc alloy, with an output switch. |
| Sensitivity | -47 dBV / Pa |
| Frequency Response | 50 Hz – 18 kHz |
| Power Supply | One AA battery or external DC 12 – 48 V phantom power | Current Drain: 2.0 mA |
| Output Impedance | Approx. 1.2 kΩ |
| Dimensions | 51 × 200 mm (Ø × L) |
| Weight | MU-90: Approx. 330 g MU-59: Approx. 360 g |
Related Videos
-
MIPRO ACT-848 Wireless System and MM-590 Microphone are Winners of Novum Design Award
Related Products
Download
| Spec Sheet | |||||
|---|---|---|---|---|---|
 |
MM-590 | Condenser / Dynamic Bifunctional Microphone (Ver.2024) | 0.24M | 2024/03/21 |  |
|
| User Guide | |||||
|---|---|---|---|---|---|
 |
MM Series | Wired Microphones (MM-90 / MM-80 / MM-70 / MM-59 / MM-39 / MM-107 / MM-590) | 2.66M | 2023/01/13 | |
|
| Brochure | |||||
|---|---|---|---|---|---|
 |
MM-590 | Condenser / Dynamic Bifunctional Microphone | 2.37M | 2022/02/08 | |
|
