MA-II Series Portable Wireless PA MA-II

MA-727
MA-828
MA-929

Product Name : MA-II Series Portable Wireless PA

*The product images and specifications shown on our website may differ from the actual products due to different versions.

ISM

The portable wireless PA systems apply MTM two-way loudspeaker systems to greatly expand the sound field, enhance sound pressure level, and present a clear and loud sound quality.
The front of the cabinet is fully covered by a speaker grille, the dimensions are close to the aesthetic golden-section ratio for better viewing pleasure.
Exclusive DSP function replaces traditional complex sound effect controls and allows quick selection of preset sound effect modes for best sound performance.
Configurable wireless receiver modules, MP3 recorder/player, USB port, SD card slot, line input jack (LINE IN), and microphone input jack (MIC IN). All audio sources can be adjusted individually.
MA-828 / MA-929 allows one optional CD player module but must be pre-fitted in the factory.
Optional UHF or ISM 2.4 / 5.8 GHz receiver modules for selection upon request.
An additional interlinking transmitter module allows more active speakers to be connected in operation by wireless linking.
The plug-in Bluetooth receiver module performs a reliable connection with smartphones or tablets to play music.
Built-in alarm siren with fade-in function and VOP (Voice Priority) function, and SUB OUT jack for an external subwoofer.
The patented retractable pulling handle combines with the bottom wheels for effortless transport.
A stand adaptor at the bottom of the cabinet allows the cabinet to be installed on a tripod stand or a subwoofer cabinet.
Built-in exclusive rechargeable battery holder allows the fast insertion of Li-ion batteries. An external AC power source can provide complete operation of the system and battery charging.
A storage compartment is provided for storing accessories.

Q'ty :

Inquiry

Product Introduction

Model	MA-727	MA-828	MA-929
Name	New Luxury Wireless PA System	New Flagship Wireless PA System	Pro Flagship Wireless PA System
Drivers	1" Treble, 2 × 5" Woofer	1" Treble, 2 × 6" Woofer	1" Treble, 2 × 8" Woofer
Output Power	170 W RMS, 295 W peak	290 W RMS, 505 W peak	290 W RMS, 505 W peak
Audio Inputs	MIC IN: 2 × combo XLR LINE IN: 1 × 3.5 mm TRS, 1 × 6.3 mm	MIC IN: 2 × combo XLR LINE IN: 1 × 3.5 mm TRS, 1 × 6.3 mm	MIC IN: 2 × combo XLR LINE IN: 1 × 3.5 mm TRS, 1 × 6.3 mm
Audio Outputs	LINE OUT: 1 × 6.3 mm SUB OUT: 1 × 6.3 mm	LINE OUT: 1 × 6.3 mm SUB OUT: 1 × 6.3 mm	LINE OUT: 1 × 6.3 mm SUB OUT: 1 × 6.3 mm
Amplifier	Class D & Class AB	Class D & Class AB	Class D & Class AB
Frequency Range	85 Hz – 17 kHz	65 Hz – 17 kHz	65 Hz – 17 kHz
Audio Control System	DSP control panel module	DSP control panel module	DSP control panel module
Other Functions	Echo, MUTE button, ALARM Siren button, VOP switch	Echo, MUTE button, ALARM Siren button, VOP switch	Echo, MUTE button, ALARM Siren button, VOP switch
Receiver Modules	Up to 2	Up to 4	Up to 8
Transmitter Modules	MTM-91, MTM-24, MTM-58 (optional)	MTM-91, MTM-24, MTM-58 (optional)	MTM-91, MTM-24, MTM-58 (optional)
Audio Player	Integrated recorder/player with SD / USB slots, plug-in Bluetooth module	Integrated recorder/player with SD / USB slots, plug-in Bluetooth module	Integrated recorder/player with SD / USB slots, plug-in Bluetooth module
Power Supply	AC 100 – 240 V	AC 100 – 240 V	AC 100 – 240 V
Battery Type	8 × 26650 Li-ion batteries (MB-28)	8 × 32700 Li-ion batteries (MB-38A)	8 × 32700 Li-ion batteries (MB-38A)
Battery Indicator	4-segment indicators (25/50/75/100%)	4-segment indicators (25/50/75/100%)	4-segment indicators (25/50/75/100%)
Standby Time	6 hours	9 hours	9 hours
Dimensions	311 × 452 × 303 mm (W × H × D)	358 × 551 × 349 mm (W × H × D)	357 × 670 × 384 mm (W × H × D)
Weight	Approx. 9.4 kg (batteries included)	Approx. 13.8 kg (batteries included)	Approx. 20.3 kg (batteries included)
Accessories	Carry bag, MS-70 tripod stand & MM-Series microphones (optional)	Carry bag, MS-70 tripod stand & MM-Series microphones (optional)	Carry bag, MS-70 tripod stand & MM-Series microphones (optional)
Note	Patented. Telecom and safety regulations approved	Patented. Telecom and safety regulations approved	Patented. Telecom and safety regulations approved

Accessories

Download


MA-727	New Luxury Wireless PA System (Ver.2024)	0.29M \| 2024/03/21
MA-828	New Flagship Wireless PA System (Ver.2024)	0.31M \| 2024/03/21
MA-929	Pro Flagship Wireless PA System (Ver.2024)	0.32M \| 2024/03/21
